Product Summary

The DSPIC30F3011-30I/P is a Digital Signal Controller.

Parametrics

DSPIC30F3011-30I/P absolute maximum ratings: (1)Ambient temperature under bias : -40℃ to +125℃; (2)Storage temperature : -65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD and MCLR) : -0.3V to (VDD + 0.3V); (4)Voltage on VDD with respect to VSS : -0.3V to +5.5V; (5)Voltage on MCLR with respect to VSS : 0V to +13.25V; (6)Maximum current out of VSS pin : 300 mA; (7)Maximum current into VDD pin (Note 2) : 250 mA; (8)Input clamp current, IIK (VI ＜ 0 or VI ＞ VDD) : ±20 mA; (9)Output clamp current, IOK (VO < 0 or VO > VDD) : ±20 mA; (10)Maximum output current sunk by any I/O pin : 25 mA; (11)Maximum output current sourced by any I/O pin : 25 mA; (12)Maximum current sunk by all ports : 200 mA; (13)Maximum current sourced by all ports (Note 2) : 200 mA.

Features

DSPIC30F3011-30I/P features: (1)Phase A, Phase B and Index Pulse input; (2)16-bit up/down position counter; (3)Count direction status; (4)Position Measurement (x2 and x4) mode; (5)Programmable digital noise filters on inputs; (6)Alternate 16-bit Timer/Counter mode; (7)Interrupt on position counter rollover/underflow.

Diagrams

DSPIC30F3011-30I/P block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DSPIC30F3011-30I/P
DSPIC30F3011-30I/P
Microchip Technology
Digital Signal Processors & Controllers (DSP, DSC) Motor Control
Data Sheet
0-1: $3.55
1-10: $2.84
10-25: $2.58
25-100: $2.35
DSPIC30F3011-30I/PT
DSPIC30F3011-30I/PT
Microchip Technology
Digital Signal Processors & Controllers (DSP, DSC) Motor Control
Data Sheet
0-1: $3.45
1-10: $2.76
10-25: $2.50
25-100: $2.28
